- Sleek, completely self-contained panel.
- Lighter weight than any other LED product on the market.
- The ULTRAPANEL’s cabinet-less design allows for maximum heat dissipation
- Easier installation, maintenance and repair.
- These panels have Enhanced Pixel Technology (EPT).
- Use on average 20% less power than other LED manufacturers.
- Available in 4mm, 5mm and 6mm indoor pitch.
Product Specifications
| Product ID: | UVIDP4-20141 | UVIDP5-20141 | UVIDP6-20141 |
| Pixel Pitch (mm): | 4 | 5 | 6.35 |
| Density (pixel/m2): | 62172 | 40187 | 24694 |
| Pixel Composition: | SMD, 1R1G1B | SMD, 1R1G1B | SMD, 1R1G1B |
| View Angle (o) : | 140(V) 140(H) | 140(V) 140(H) | 140(V) 140(H) |
| Brightness (cd/m2): | 2600 | 2800 | 3000 |
| Driving Way: | N/A | N/A | 1/4 scan |
| Control Way: | true pixel | true pixel | true pixel |
| Module Size (ft/in): | 1'*2' | 1'*2' | 1'*2' |
| Module Size (m): | .3048*.6096 | .3048*.6096 | .3048*.6096 |
| Cabinet Size (ft/in): | 4'*6'*4' | 4'*6'*4' | 4'*6'*4' |
| Cabinet Size (m): | 1.2192*1.8288*.1016 | 1.2192*1.8288*.1016 | 1.2192*1.8288*.1016 |
| Modules/Cabinet: | 12 | 12 | 12 |
| Cabinet/Pixel (pixel): | 304*456=138,642 | 244*366=89,394 | 192*288=55,296 |
| Pixel/Module (pixel): | 76*152=11,552 | 61*122=7442 | 48*96=4608 |
| Cabinet Weight (kg/m2): | 48kg | 48kg | 48kg |
